GPS-RECEIVER JP7-T

0.5 Order options

Before you start up the receiver, make sure that your package includes the
following items. If any item is missing or damaged, please contact your
vendor immediately. According to your requirements you can choose the
desired unit. In the figure below the available components are marked with
red colour. (In order to have a clearly view and to detect the required option
of JP7-T family imaged below, please print this page with a colour printer.)
The table below contains the order options of JP7-T family.
Name
JP7-T 30-pin out on the left and right side of JP7-T are available for use
JP7-TB
JP7-TC
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
48 Balls are available for use
A 50-pin connector and a RF connector are
JP7-TC-1
A 50-pin connector and solder pads for an antenna
JP7-TC-2
There is no antenna cable included in the delivery
Options
available for use
cable are available for use.
package.
