Balls Assignment Of The Jp7-Tb - FALCOM JP7-T Series Hardware Description

GPS-RECEIVER JP7-T
Pin Name
18 RF_GND
19 V_ANT
20 VC3.0
21 V_BAT
22 RESET_N
23 GPIO10
24 GPIO6
25 GPIO5
26 GPIO7
27 GPIO0
28 GPIO1
29 T-MARK
30 GND
Table 4:

6.7 Balls assignment of the JP7-TB

Figure 4:
Th is confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
I/O
Analog ground
I Power supply for active antenna
O Supply voltage of RF section
I Power for RTC and SRAM
I Resets the unit if active LOW
I/O See chapter
I/O See chapter
I/O See chapter
I/O See chapter
I/O See chapter
I/O See chapter
O One pulse per second
Digital ground
Pin assignment of the JP7-T
Balls assignment of the JP7-TB
Description
6.8.4
6.8.4
6.8.4
6.8.4
6.8.4
6.8.4
VERSION 1.02
Level
upto +12 V DC
+3.0 V DC
+3 V DC ±5%
CMOS
CMOS
CMOS
CMOS
CMOS
CMOS
CMOS
CMOS
Page 25
