FALCOM JP7-T Series Hardware Description page 17

GPS-RECEIVER JP7-T
Example:
$PSRF107,0,200,200*3D
The receiver will be set in Trickle Power mode where 20% of time it will spend for
tracking and the tracking period will takes 200 msec.
Table 1: Example of Trickle Power Mode Control.
Note:
If the receiver is set into the Trickle Power Mode, the high data rate
transmission is recommend as suitable.
Computation of Duty Cycle and On Time
The Duty Cycle is the desired time, which will be spent for tracking. The
On Time is the duration of each tracking period (range is 200 - 900 msec.)
To calculate the Trickle Power update rate as a function of Duty Cycle and
On Time, use the following formula:
On Time – (Duty Cycle * On Time)
Off Time = ---------------------------------------------
Update rate = Off Time + On Time
Hint:
It is not possible to enter an On Time > 900 msec.
Following are some examples of selections:
Mode
Continuous
Trickle Power
Trickle Power
Trickle Power
Trickle Power
Table 2: Example of Selections for Trickle Power Mode of Operation.
On Time
1 2
(msec)
200 √ √
√ √
300
400 √ √
√ √
500
√ √
600
√
700
√
800
√
900
Table 3: Trickle Power supported Modes.
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
Duty Cycle
On Time (msec)
1000
200
200
300
500
Update Rates (seconds)
3 4 5
√ √ √
√ √ √
√ √ √
√ √ √
√ √ √
√ √ √
√ √ √
√ √ √
Duty Cycle (%)
100
20
10
10
5
6 7 8
√ √ √
√ √ √
√ √ √
√ √ √
√ √ √
√ √ √
√ √ √
√ √ √
VERSION 1.02
Update Rate (1/Hz)
1
1
2
3
10
9 10
√ √
√ √
√ √
√ √
√ √
√ √
√ √
√ √
Page 17
