6.3.6 4-** Limits / Warnings

Par. Parameter description
No. #
4-1* Motor Limits
4-10 Motor Speed Direction
4-11 Motor Speed Low Limit [RPM]
4-12 Motor Speed Low Limit [Hz]
4-13 Motor Speed High Limit [RPM]
4-14 Motor Speed High Limit [Hz]
4-16 Torque Limit Motor Mode
4-17 Torque Limit Generator Mode
4-18 Current Limit
4-19 Max Output Frequency
4-5* Adj. Warnings
4-50 Warning Current Low
4-51 Warning Current High
4-52 Warning Speed Low
4-53 Warning Speed High
4-54 Warning Reference Low
4-55 Warning Reference High
4-56 Warning Feedback Low
4-57 Warning Feedback High
4-58 Missing Motor Phase Function
4-6* Speed Bypass
4-60 Bypass Speed From [RPM]
4-61 Bypass Speed From [Hz]
4-62 Bypass Speed To [RPM]
4-63 Bypass Speed To [Hz]
4-64 Semi-Auto Bypass Set-up
Default value
[2] Both directions
SR
SR
SR
SR
SR
100.0 %
SR
SR
0.00 A
ImaxVLT (P1637)
0 RPM
outputSpeedHighLimit (P413)
-999999.999 N/A
999999.999 N/A
-999999.999 ProcessCtrlUnit
999999.999 ProcessCtrlUnit
[2] Trip 1000 ms
SR
SR
SR
SR
[0] Off
®
MG.16.A1.02 - VLT is a registered Danfoss trademark
6 How to Programme the Low Harmonic Drive
4-set-up Change dur-
ing operation
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
Conver- Type
sion index
- Uint8
67 Uint16
-1 Uint16
67 Uint16
-1 Uint16
-1 Uint16
-1 Uint16
-1 Uint32
-1 Uint16
-2 Uint32
-2 Uint32
6
67 Uint16
67 Uint16
-3 Int32
-3 Int32
-3 Int32
-3 Int32
- Uint8
67 Uint16
-1 Uint16
67 Uint16
-1 Uint16
- Uint8
125
