VLT HVAC Low Harmonic Drive Operating In-
structions
5-13 Terminal 29 Digital Input
Option:
[14] * Jog
5-14 Terminal 32 Digital Input
Option:
[0] * No Operation
5-15 Terminal 33 Digital Input
Option:
[0] * No Operation
5-40 Function Relay
Array [8]
(Relay 1 [0], Relay 2 [1]
Option MCB 105: Relay 7 [6], Relay 8 [7] and Relay 9 [8]).
Select options to define the function of the relays.
The selection of each mechanical relay is realised in an array parameter.
Option:
[0] * No operation
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Standby / no warning
[5] * Running
[6] Running / no warning
[8] Run on ref/no warn
[9] * Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedb. range
[19] Below feedback, low
[20] Above feedback, high
[21] Thermal warning
[25] Reverse
[26] Bus OK
[27] Torque limit & stop
[28] Brake, no brake war
[29] Brake ready, no fault
[30] Brake fault (IGBT)
Function:
Select the function from the available digital input range and the additional options [60], [61], [63]
and [64]. Counters are used in Smart Logic Control functions.This parameter is available for FC 302
only.
Functions are described under 5-1*
Function:
Same options and functions as par. 5-1*
Function:
Same options and functions as par. 5-1*
Function:
Default setting for relay 2.
Default setting for relay 1.
®
MG.16.A1.02 - VLT is a registered Danfoss trademark
6 How to Programme the Low Harmonic Drive
Digital Inputs
Digital Inputs , except for Pulse input .
Digital Inputs .
6
