VLT HVAC Low Harmonic Drive Operating In-
structions
6-25 Terminal 54 High Ref./Feedb. Value
Range:
100.000 N/ [-999999.999 - 999999.999 N/A]
A*
6-26 Terminal 54 Filter Time Constant
Range:
0.001 s* [0.001 - 10.000 s]
6-27 Terminal 54 Live Zero
Option:
[0] Disabled
[1] * Enabled
6-50 Terminal 42 Output
Option:
[0] * No operation
[100] Output freq. 0-100
[101] Reference Min-Max
[102] Feedback +-200%
[103] Motor cur. 0-Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] * Speed 0-HighLim
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[130] Out frq 0-100 4-20mA
[131] Reference 4-20mA
[132] Feedback 4-20mA
[133] Motor cur. 4-20mA
[134] Torq.0-lim 4-20 mA
[135] Torq.0-nom 4-20mA
[136] Power 4-20mA
[137] Speed 4-20mA
Function:
Enter the analog input scaling value that corresponds to the high voltage/high current value set in
Terminal 54 High Voltage and par. 6-23 Terminal 54 High Current .
par. 6-21
Function:
Enter the time constant. This is a first-order digital low pass filter time constant for suppressing
electrical noise in terminal 54. A high time constant value improves dampening but also increases
the time delay through the filter.
This parameter cannot be adjusted while the motor is running.
Function:
This parameter makes it possible to disable the Live Zero monitoring. E.g. to be used if the analog
outputs are used as part of a de-central I/O system (e.g. when not as part of any frequency con-
verter related control functions, but feeding a Building Management System with data).
Function:
Select the function of Terminal 42 as an analog current output. A motor current of 20 mA corre-
sponds to I .
max
0 - 100 Hz, (0-20 mA)
Minimum reference - Maximum reference, (0-20 mA)
Maximum Reference/Feedb. , (0-20 mA)
-200% to +200% of par. 20-14
0 - Inverter Max. Current (par. 16-37
0 - Torque limit (par. 4-16 Torque Limit Motor Mode ), (0-20 mA)
0 - Motor rated torque, (0-20 mA)
0 - Motor rated power, (0-20 mA)
0 - Speed High Limit (par. 4-13 Motor Speed High Limit [RPM] and par. 4-14 Motor Speed High Limit
[Hz] ), (0-20 mA)
0 - 100%, (0-20 mA)
0 - 100%, (0-20 mA)
0 - 100%, (0-20 mA)
0 - 100 Hz
Minimum Reference - Maximum Reference
Maximum Reference/Feedb.
-200% to +200% of par. 20-14
0 - Inverter Max. Current (par. 16-37
0 - Torque limit (par. 4-16 Torque Limit Motor Mode )
0 - Motor rated torque
0 - Motor rated power
0 - Speed High Limit (4-13 and 4-14)
®
MG.16.A1.02 - VLT is a registered Danfoss trademark
6 How to Programme the Low Harmonic Drive
Inv. Max. Current ), (0-20 mA)
Inv. Max. Current )
