6 How to Programme the Low Harmonic Drive
Illustration 6.8: Step 7: Use the up/down navigation keys to
select between the different choices. Press [OK].
Function Set-ups parameters
The Function Set-ups parameters are grouped in the following way:
6
Q3-10 Adv. Motor Settings
Motor Thermal Protection Par. 6-50 Terminal 42 Output
Par. 1-90
Thermistor Source
Par. 1-93
Automatic Motor Adapta-
Par. 1-29
tion (AMA)
Par. 14-01 Switching Frequency
Par. 4-53 Warning Speed High
Q3-20 Digital Reference
Minimum Reference
Par. 3-02
Maximum Reference
Par. 3-03
Par. 3-10 Preset Reference
Par. 5-13 Terminal 29 Digital Input
Par. 5-14 Terminal 32 Digital Input
Terminal 33 Digital Input
Par. 5-15
92
Q3-1 General Settings
Q3-11 Analog Output Q3-12 Clock Settings
Par. 0-70
Terminal 42 Output Min
Par. 6-51 Par. 0-71
Scale
Terminal 42 Output Max
Par. 6-52 Par. 0-72
Scale
Par. 0-74
Par. 0-76
Par. 0-77
Q3-2 Open Loop Settings
MG.16.A1.02 - VLT
VLT HVAC Low Harmonic Drive Operating In-
Q3-13 Display Settings
Date and Time
Par. 0-20
Date Format
Par. 0-21
Time Format
Par. 0-22
DST/Summertime Par. 0-23
DST/Summertime Start Par. 0-24
DST/Summertime End
Par. 0-37
Par. 0-38
Par. 0-39
Q3-21 Analog Reference
Minimum Reference
Par. 3-02
Maximum Reference
Par. 3-03
Par. 6-10 Terminal 53 Low Voltage
Par. 6-11 Terminal 53 High Voltage
Par. 6-12 Terminal 53 Low Current
Terminal 53 High Current
Par. 6-13
Terminal 53 Low Ref./Feedb. Value
Par. 6-14
Terminal 53 High Ref./Feedb. Value
Par. 6-15
®
is a registered Danfoss trademark
structions
Display Line 1.1 Small
Display Line 1.2 Small
Display Line 1.3 Small
Display Line 2 Large
Display Line 3 Large
Display Text 1
Display Text 2
Display Text 3
