6 How to Programme the Low Harmonic Drive
Parameter
Par. 0-01 Language
Motor Power [kW]
Par. 1-20
Motor Power [HP]
Par. 1-21
Motor Voltage *
Par. 1-22
Motor Frequency
Par. 1-23
Par. 1-24 Motor Current
Par. 1-25 Motor Nominal Speed
Par. 1-28 Motor Rotation Check
Ramp 1 Ramp Up Time
Par. 3-41
Ramp 1 Ramp Down Time
Par. 3-42
Motor Speed Low Limit [RPM]
Par. 4-11
Motor Speed Low Limit [Hz] *
Par. 4-12
Par. 4-13 Motor Speed High Limit [RPM]
Par. 4-14 Motor Speed High Limit [Hz] *
Jog Speed [RPM]
Par. 3-19
Jog Speed [Hz] *
Par. 3-11
6
Terminal 27 Digital Input
Par. 5-12
Function Relay **
Par. 5-40
Table 6.2: Quick Setup parameters
*The display showing depends on choices made in par. 0-02
Speed Unit and par. 0-03 Regional Settings depend on which region of the world the frequency converter is supplied to but can be re-programmed as
required.
Function Relay , is an array, where one may choose between Relay1 [0] or Relay2 [1]. Standard setting is Relay1 [0] with the default choice
** Par. 5-40
Alarm [9].
See the parameter description in the section
For a detailed information about settings and programming, please see the
x=version number
NB!
If [No Operation] is selected in par. 5-12
If [Coast Inverse] (factory default value) is selected in par. 5-12
start.
0-01 Language
Option:
[0] * English
[1] Deutsch
[2] Francais
[3] Dansk
[4] Spanish
[5] Italiano
Svenska
[7] Nederlands
86
[Units]
[kW]
[HP]
[V]
[Hz]
[A]
[RPM]
[Hz]
[s]
[s]
[RPM]
[Hz]
[RPM]
[Hz]
[RPM]
[Hz]
Motor Speed Unit and par. 0-03 Regional Settings . The default settings of par. 0-02 Motor
Commonly Used Parameters .
VLT HVAC Drive Programming Guide, MG.11.CX.YY
y=language
Terminal 27 Digital Input , no connection to +24 V on terminal 27 is necessary to enable start.
Terminal 27 Digital Input , a connection to +24V is necessary to enable
Function:
Defines the language to be used in the display. The frequency converter can be delivered with 4
different language packages. English and German are included in all packages. English cannot be
erased or manipulated.
Part of Language packages 1 - 4
Part of Language packages 1 - 4
Part of Language package 1
Part of Language package 1
Part of Language package 1
Part of Language package 1
Part of Language package 1
Part of Language package 1
®
