8 General Specifications

8.2 Filter Specifications

Frame size
Voltage [V]
Current, RMS [A]
Peak Current [A]
RMS overload [%]
Response time [ms]
Settling time - reactive current control
[ms]
Settling time - harmonic current control
(filtering) [ms]
Overshoot - reactive current control [%]
Overshoot - harmonic current control
[%]
Table 8.1: Power Ranges (LHD with AF)
8
168
D E
380 - 480 380 - 480
120 210
340 595
No Overload
< 0.5
< 40
< 20
< 20
< 10
®
MG.16.A1.02 - VLT is a registered Danfoss trademark
VLT HVAC Low Harmonic Drive Operating In-
F
380 - 480
330 Nominal value
935 Amplitude value of the current
60 seconds in 10 min
