6 How to Programme the Low Harmonic Drive
Q3-40 Fan Functions
Broken Belt Function
Par. 22-60
Broken Belt Torque
Par. 22-61
Broken Belt Delay
Par. 22-62
Semi-Auto Bypass Set-up
Par. 4-64
Par. 1-03 Torque Characteristics
Par. 22-22 Low Speed Detection
Par. 22-23 No-Flow Function
No-Flow Delay
Par. 22-24
Minimum Run Time
Par. 22-40
Minimum Sleep Time
Par. 22-41
Wake-up Speed [RPM]
Par. 22-42
Par. 22-43 Wake-up Speed [Hz]
Par. 22-44 Wake-up Ref./FB Difference
Setpoint Boost
Par. 22-45
Maximum Boost Time
Par. 22-46
6
Brake Function
Par. 2-10
AC brake Max. Current
Par. 2-16
Par. 2-17 Over-voltage Control
Par. 1-73 Flying Start
Par. 1-71 Start Delay
Function at Stop
Par. 1-80
DC Hold/Preheat Current
Par. 2-00
Motor Speed Direction
Par. 4-10
VLT HVAC Drive Programming Guide for a detailed description of the Function Setups parameter groups.
See also
1-00 Configuration Mode
Option:
[0] * Open Loop
[3] Closed Loop
NB!
This parameter cannot be changed when motor is running.
NB!
When set for Closed Loop, the commands Reversing and Start Reversing will not reverse the direction of the motor.
94
Q3-4 Application Settings
Q3-41 Pump Functions
Low Power Auto Set-up
Par. 22-20
Low Power Detection
Par. 22-21
Low Speed Detection
Par. 22-22
No-Flow Function
Par. 22-23
Par. 22-24 No-Flow Delay
Par. 22-40 Minimum Run Time
Par. 22-41 Minimum Sleep Time
Wake-up Speed [RPM]
Par. 22-42
Wake-up Speed [Hz]
Par. 22-43
Wake-up Ref./FB Difference
Par. 22-44
Setpoint Boost
Par. 22-45
Par. 22-46 Maximum Boost Time
Par. 22-26 Dry Pump Function
Dry Pump Delay
Par. 22-27
Flow Compensation
Par. 22-80
Square-linear Curve Approximation
Par. 22-81
Work Point Calculation
Par. 22-82
Par. 22-83 Speed at No-Flow [RPM]
Par. 22-84 Speed at No-Flow [Hz]
Par. 22-85 Speed at Design Point [RPM]
Speed at Design Point [Hz]
Par. 22-86
Pressure at No-Flow Speed
Par. 22-87
Pressure at Rated Speed
Par. 22-88
Flow at Design Point
Par. 22-89
Par. 22-90 Flow at Rated Speed
Par. 1-03 Torque Characteristics
Par. 1-73 Flying Start
Function:
Motor speed is determined by applying a speed reference or by setting desired speed when in Hand
Mode.
Open Loop is also used if the frequency converter is part of a closed loop control system based on
an external PID controller providing a speed reference signal as output.
Motor Speed will be determined by a reference from the built-in PID controller varying the motor
speed as part of a closed loop control process (e.g. constant pressure or flow). The PID controller
must be configured in par. 20-** or via the Function Setups accessed by pressing the [Quick Menus]
button.
®
MG.16.A1.02 - VLT is a registered Danfoss trademark
VLT HVAC Low Harmonic Drive Operating In-
Q3-42 Compressor Functions
Torque Characteristics
Par. 1-03
Start Delay
Par. 1-71
Short Cycle Protection
Par. 22-75
Interval between Starts
Par. 22-76
Par. 22-77 Minimum Run Time
Par. 5-01 Terminal 27 Mode
Par. 5-02 Terminal 29 Mode
Terminal 27 Digital Input
Par. 5-12
Terminal 29 Digital Input
Par. 5-13
Function Relay
Par. 5-40
Flying Start
Par. 1-73
Par. 1-86 Trip Speed Low [RPM]
Par. 1-87 Trip Speed Low [Hz]
