6 How to Programme the Low Harmonic Drive
Par. Parameter description
No. #
21-5* Ext. CL 3 Ref./Fb.
21-50 Ext. 3 Ref./Feedback Unit
21-51 Ext. 3 Minimum Reference
21-52 Ext. 3 Maximum Reference
21-53 Ext. 3 Reference Source
21-54 Ext. 3 Feedback Source
21-55 Ext. 3 Setpoint
21-57 Ext. 3 Reference [Unit]
21-58 Ext. 3 Feedback [Unit]
21-59 Ext. 3 Output [%]
21-6* Ext. CL 3 PID
21-60 Ext. 3 Normal/Inverse Control
21-61 Ext. 3 Proportional Gain
21-62 Ext. 3 Integral Time
21-63 Ext. 3 Differentation Time
6
21-64 Ext. 3 Dif. Gain Limit
140
VLT HVAC Low Harmonic Drive Operating In-
Default value
[1] %
0.000 ExtPID3Unit
100.000 ExtPID3Unit
[0] No function
[0] No function
0.000 ExtPID3Unit
0.000 ExtPID3Unit
0.000 ExtPID3Unit
0 %
[0] Normal
0.01 N/A
10000.00 s
0.00 s
5.0 N/A
®
MG.16.A1.02 - VLT is a registered Danfoss trademark
4-set-up Change dur- Conver-
ing operation sion index
All set-ups TRUE -
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -1
structions
Type
Uint8
Int32
Int32
Uint8
Uint8
Int32
Int32
Int32
Int32
Uint8
Uint16
Uint32
Uint16
Uint16
