SDLT 600 Product Manual
Loader Connector
RS-422 (8 pin)

Figure 4-6. Connectors on the Back Panel of SDLT 600 Tape Drive

Table 4-3. MSE and SE Mode SCSI Connector Pin Assignments

Signal Name
Ground
Ground
Ground
Ground
Ground
Ground
Ground
Ground
Ground
81-81184-02 REV A01
Power Connector
(4 pin)
SCSI ID Jumper Block
(No jumpers on this block
selects default SCSI ID of 5)
Pin Number
1
2
3
4
5
6
7
8
9
Controller Diag Port (8 pin)
(Diagnostic use only)
TERMPWR Block
(4 pin)
Pin Number
35
36
37
38
39
40
41
42
43
March 2004
Chapter 4: Installing Your Tape Drive
SCSI Port
(68 pin)
Pin # 1
or
Denotes Pin # 1
Signal Name
-DB(12)
-DB(13)
-DB(14)
-DB(15)
-DB(P1)
-DB(0)
-DB(1)
-DB(2)
-DB(3)
4-13
