Product Specifications

Table 3-1. SDLT 600 Tape Drive Interface Versions Speeds and Options

Interface
Versions
Fibre
Channel
*
Ultra 160
* Fibre Channel interface not available in the tabletop model.
** The SCSI bus itself limits this speed, not the design of SDLT 600 tape drive or Super DLTtape II media.

Ultra 160 SCSI Interface

The Ultra 160 SCSI interface provides a low-voltage differential (LVD) mode running up to
160 MB/second and a single-ended (SE) mode running up to 40 MB/second.
N
OTE
The tape drive automatically senses the SCSI bus mode and switches between LVD and SE
accordingly. Although the tape drive defaults to LVD, it switches to SE if the SCSI bus operates in SE
mode. For example, if the SCSI controller card is SE (or multimode set to SE), the tape drive
automatically switches to SE mode. Also, if any device on the SCSI bus is SE, the entire bus switches
to SE, including the tape drive.
3-2
Speeds
• 100 MB/second
• 200 MB/second
• 160 MB/second maximum burst speed
: The host computer's SCSI controller card may limit these speeds. To
achieve the best performance, make sure the SCSI controller card can
operate at 160 MB/second.
Protocol Options
• Class3
• Connect to N port, NL port, FL port
• FC-MI
• FC-AL-2
• FCP-2
• FC-FS
• SCSI-3 (SAM-2, SPC-2, or SSC)
• Multi-mode Single-Ended (MSE) provides one
**
of two differential senses:
- Low Voltage Differential (LVD) running up to
160 MB/second, or
- Single Ended (SE) running up to 40
MB/second
• Ultra 160 2/FAST-20/Asynchronous
• SCSI-3 (SAM-2, SPC-2, and SSC)
• Supports up to 15 hosts
