Table 4-1. SCSI ID Address Selections (Graphical Format)

SCSI ID
Jumper Block
SCSI ID
Jumper Block
SCSI ID
Jumper Block
SCSI ID
Jumper Block
N
OTE
SCSI ID Jumper Block
(No jumpers on this block
selects default SCSI ID of 5)

Figure 4-2. 10-pin SCSI ID Jumper Block on Rear of Tape Drive

81-81184-02 REV A01
0
4
8
12
: The computer system and the tape drive SCSI IDs are only checked at
power-on. To change the SCSI ID after installation, power off both the
system and the tape drive, change the tape drive's SCSI ID, power on the
tape drive, and then power on the system.
1 2
5 (default) 6
9 10
13 14
March 2004
Chapter 4: Installing Your Tape Drive
3
7
11
15
4-7
