Functional Specifications

Table 3-14. Non-Operating Vibration Specifications (Packaged)

Vibration (Packaged)
Type
Frequency Range
Application
Type
Frequency Range
Application
* Air and truck profiles are specified in ASTM D4728, Standard Test Method for Random Vibration
Testing of Shipping Containers.

Table 3-15. Operating Shock and Vibration Specifications

Shock
Pulse Shape
Peak Acceleration
Duration
Application
Vibration
Type
Frequency Range
Acceleration Level
Application
3-10
Random
Truck Profile* (0.5 Grms)
Air Profile* (1.0 Grms)
X,Y,Z axes (30 minutes, each profile and each axis, for a total of 3
hours)
Sine, Sweep, and Dwell
5 to 150 to 5 Hz; 0.5 octave/minute, 0.5 G
X,Y,Z axes; dwell at lowest resonant frequency in axis for 30
minutes.
Additional 30 minutes for each additional resonance; up to 4
resonances total.
½ sine pulse
10 G
10 ms
X,Y,Z axes, twice in each axis (once in each direction)
Sine Sweep
5 to 500 to 5 Hz Upward and downward sweep
0.25 G Between 22 and 500 Hz
0.010" DA Between 5 and 22 Hz (crossover)
X,Y,Z axes Sweep rate = 1.0 octave/minute
