SDLT 600 Product Manual
3.2.2

Shock and Vibration Specifications

The following tables provide non-operating and operating shock and vibration specifications for the
SDLT 600 tape drive system.

Table 3-11. Non-Operating Shock Specifications (Unpackaged)

Shock (Unpackaged)
Pulse Shape
Peak Acceleration
Duration
Application

Table 3-12. Non-Operating Shock Specifications (Packaged, Drop)

Shock (Packaged,
Drop)
Drop

Table 3-13. Non-Operating Vibration Specifications (Unpackaged)

Vibration (Unpackaged)
Type
Frequency Range
Acceleration Level
Application
Type
Frequency Range
Acceleration Level
PSD Envelope
Application
81-81184-02 REV A01
Square wave
40 G
10 ms (180 inches/second)
X,Y,Z axes, twice in each axis (once in each direction)
Height Number
of Drop of Drops
42 inches 16 drops total
36 inches 16 drops total
Sine
5 to 500 to 5 Hz
0.02" DA
1.0 G
X,Y,Z axes
Random
10 to 500 Hz
2.0 G
2
0.008 G /Hz
X,Y,Z axes
March 2004
Chapter 3: SDLT 600 Tape Drive Specifications
½ sine pulse
140 G
2 ms
Package Weight
0 lbs. < package weight
20 lbs. < package weight
Sweep
Upward and downward sweep
Between 5 and 31 Hz (crossover)
Between 31 and 500 Hz (crossover)
Sweep rate = ½ octave/minute
Sweep rate = 60 minutes/axis
20 lbs.
50 lbs.
3-9
