Configuring the Tape Drive

Figure 4-9 on page 4-21
This model of tape drive is normally configured to meet customer specifications before leaving the
factory, so should not require any internal configuration changes on site.

SCSI ID

Selector

Figure 4-9. Back Panel of the Tabletop Model

SCSI ID
The SCSI ID default for the tabletop tape drive is set to 3; you can configure the tape drive for SCSI ID
addresses that range from 0 to 15 using the SCSI ID pushbutton. Press the button above or below the
ID number display to set the desired SCSI ID. The top button increases the ID number, the bottom
button decreases the ID number.
switch and its location on the rear of the tabletop model of the SDLT 600 tape drive.
81-81184-02 REV A01
shows the location of the controls and connectors for the tabletop tape drive.
Fan
Figure 4-10 on page 4-22
Power
Connector
shows a close-up view of the SCSI ID
March 2004
Chapter 4: Installing Your Tape Drive
SCSI
Connectors
Power
Switch
4-21
