Configuring and Installing an Internal Tape Drive with SCSI Interface
Table 4-4. MSE LVD Mode SCSI Connector Pin Assignments (Continued)
Signal Name
+C/D
+REQ
+I/O
+DB(8)
+DB(9)
+DB(10)
+DB(11)
Table 4-5. 4-Pin Power Connector Pin Assignments
Pin Number
1
2
3
4
Table 4-6. 8-Pin Loader Connector Pin Assignments
Signal Name
Ground
REC_FROM_LOADER_H
REC_FROM_LOADER_L
Ground
4-16
Pin Number
28
29
30
31
32
33
34
Signal Name
+12 VDC
Ground (+12V return)
Ground (+5V return)
+5 VDC
Pin Number
1
2
3
4
March 2004
Pin Number
62
63
64
65
66
67
68
Pin Number
Signal Name
5
SEND_TO_LOADER_H
6
SEND_TO_LOADER_L
7
Ground
8
LOADER_PRESENT_L
SDLT 600 Product Manual
Signal Name
-C/D
-REQ
-I/O
-DB(8)
-DB(9)
-DB(10)
-DB(11)
81-81184-02 REV A01
