SDLT 600 Product Manual
A.5

Loading a Data Cartridge

Complete this subsection to load a data cartridge into the front of the tape drive; refer to
needed.
1. Insert the data cartridge into the front of the tape drive, as shown in
Push the data cartridge fully into the tape drive.
2.
The Drive Status LED flashes to show that the media is loading. When the media reaches the
Beginning of Tape (BOT) marker, the LED lights steadily. The data cartridge is now ready for use.
Data Cartridge

Figure A-7. Loading a Super DLTtape II Data Cartridge

81-81184-02 REV A01
Appendix A: Super DLTtape I and Super DLTtape II Data Cartridges
Tape Drive
Drive Status LED
March 2004
Figure A-7
Figure A-7.
Eject Button
as
A-9
