Data Cartridge Inspection Procedure
5. Refer to
partially visible. The reel locks are black. The reel locks can break if you drop the data cartridge. If
the reel lock tabs are not visible, do not use the data cartridge.

Figure B-2. DLTtape VS1 Data Cartridge Reel Locks

Look closely at the spring-loaded reel hub on the bottom of the data cartridge. Verify that the hub
6.
is centered within the circular opening in the data cartridge. Gently press the hub and be certain
that it springs back into place—centered within its circular opening and completely flush with the
plastic shell.
fails this step.

Figure B-3. Faulty Data Cartridge Spring-loaded Reel Hub

B-4
Figure B-2 and check the reel lock openings to ensure the small plastic tabs inside are
Reel Lock
Figure B-3 shows a defective spring-loaded reel hub. Do not use a data cartridge that
Data cartridge hub is recessed slightly, and when pressed, does
not return to a position that is flush with the plastic shell
March 2004
SDLT 600 Product Manual
Reel Lock
81-81184-02 REV A01
