SDLT 600 Product Manual

Figure 3-1. Multiple Layers Comprise Super DLTtape II Media

3.4.2

Physical Data Cartridge

A durable plastic case encloses the Super DLTtape II media, as shown in

Figure 3-2. Super DLTtape II Data Cartridge

81-81184-02 REV A01
High Coercivity
Magnetic Layer
Under Layer
Enhanced Base
Film Layer
Back Coat Layer
with Servo Guides
Layers not drawn to scale
March 2004
Chapter 3: SDLT 600 Tape Drive Specifications
Figure 3-2.
3-17
