Kessel EasyClean SkimTech Basic Translation Of Original Instruction Manual page 65

Remove sieve screw:
▶ Loosen screws with lock nuts on the flange cover. ➊
▶ Remove top section including sieve screw. ➋
▶ Remove any coarse materials and jammed objects from sieve screw with the
help of the long-handled brush. ➌
▶ Clean the sieve screw and sieve basket with warm water. ➍
▶ Check brushes for wear, replace if necessary. ➎
L When replacing brushes, all brushing elements must be replaced.
▶ Give the interior of the tank a general clean.
▶ Re-fit in reverse order and observe the stipulated torques ( Chap."3.
Technical data").
016-100_01 Installation and operating manual
1
2
3 4
5
Fig. [16]
65
