4.

Assembling and connecting the system

4.1 Select suitable installation location
Assembling the system:
▶ Select a room with good aeration and/or ventilation as well as a level
assembly surface with adequate load-bearing capacity.
▶ Assure room temperature with frost protection and a maximum tempera-
ture of 45°C (80% humidity).
▶ Room height at least 60 cm higher than the system so that the service
access covers can be opened during cleaning work.
▶ Assure free working space of at least 1 m around the system.
▶ Inlet with calming section of at least "DN of the inlet pipe" x 10 (slope 2%).
Transition of building-side downpipe to calming section equipped with 2 x
45° bends .
1
4.2 Safe assembly
Transport risk / system's own weight!
Observe weight of the system / system components ( Chap."3.
Technical data").
▶ Pay attention to correct lifting and ergonomic factors.
▶ Do not use cranes to move the system.
1) reduction of the risk of sucking empty siphons and odour traps. Less air inclusion and air movement as well as odour and foam build-up in the system..
50
Installing the system
Use suitable lifting gear (e.g. cable winch or forklift) to erect lying
components. Use lifting eyes attached to coarse filter unit for
safety.
