9.4 Coarse filter unit maintenance
▶ Remove disposal hose. ➊.
▶ Loosen clamp on the disposal hose.
▶ Set the disposal hose to the side.
Danger of toppling! The centre of gravity of the sieve screw lies
inconveniently.
▶ Set the sieve screw down slowly in order to compensate for the lever
effect.
▶ Secure the sieve screw with pins.
▶ Swing out the interior part:
▶ Loosen the Torx screws (TX50 - 3x) on the service access cover
(small opening) and set aside safely. ➋
▶ Lift off the cover and set to the side. 
▶ Loosen the clamp with a screwdriver and slide over the stainless
steel nozzle of the sieve screw. ➍
▶ Loosen the clamping ring of the service access cover. ➎
▶ Swing out the sieve screw ➏ and lock in horizontal position using
the pins. 
64 Installation and operating manual
1
2
3
5
4
7
6
Fig. [15]
