5 Technical specifications

5.1 Data and measurements

Model: Loop
SORG
Type: 802
German Aid Indix Nr.: 26.99.01.3034/ German Aid Indix Nr.: 26.99.01.1045 with 12"/16"-wheels
All measurements ± 5%
Indication
size 1
size 2
size 3
back height
back unit
leg supports recording
tilting
back angle
lower leg length
ETRTO wheel size
ETRTO wheel size
ETRTO wheel size
ETRTO wheel size
diameter handrim
handrim
camber
Seat height (SH)
with horizontal seat and
horizontal frame
Wide seat shell base abso-
lutely
Length of seat shell base
frame absolutely
Height seat shell base
frame absolutely
Height of seat shell base
frame folded back
incline
descent
stability
turning circle
load capacity (max.)/
weight testdummy
tare
heaviest piece
wheel
corrosion protection
length of use of the
wheelchair
life cycle of the wheelchair
Normative requirements
42 of 44
Measurements Comment
usable width = frame BH 300-420 mm
width + 40 mm in 40 mm steps
usable width = frame BH 340-460 mm
width + 40 mm in 40 mm steps
usable width = frame BH 380-500 mm
width + 40 mm in 40 mm steps
430 or 580 mm
can be moved back by approx. 60 mm
about 60 mm forward displaceable
from -5° to +35°
from +2,5° to +40°
90 - 120°
120 - 550 mm
at 20" Ø 451 mm
at 22" Ø 489 mm
at 24" Ø 540 mm
at 12" Ø 203 mm
at 20" 444 mm
at 22" 481 mm
at 24" 533 mm
Ø 19 mm
0° or 2°
rear wheel 20"/22" 410 mm size 1
caster 5"/5,5" 430 mm size 3
rear wheel 20"/22" 420 mm size 1
caster 6"/7" 440 mm size 3
rear wheel 24" 430 mm size 1
caster 5"/6" 450 mm size 3
rear wheel 24" 445 mm size 1
caster 7" 465 mm size 3
min. BH + 220 mm
max. BH + 300 mm
min. 610 mm at frame size 1, 12"-rear wheel and normal foot
plate (160 mm)
max. 1130 mm at frame size 3, 24"-rear wheel, wheel base extensi-
on and wide footplate (230 mm)
min. 900 - 1000 mm
max. 1050 - 1150 mm
min. 1000 - 1100 mm
1150 - 1250 mm
min. 550 mm
max. 620 mm
12% = 7°
12% = 7°
12% = 7°
ca. 1100 mm
120 kg
suitable for driving: 15,1 kg
BH 300 mm, rear wheel
12", caster 4"PU
rear wheel 1,2 - 2,2 kg
commercial pneumatic tires, sizes 1 ", 1 3/8" or puncture-proof tires (same dimensions),
tire inflation pressure usually 3-10 bar
material Stainless steel, aluminum
coating Powder coating, galvanizing
3 years at not excessive demand
5 years
The wheelchair meets the requirements of ISO 7176-8 and the requirements
against ignition.
Service Record Loop
suitable from SD 320 mm, each BH +
40 mm growable
suitable from SD 320 mm, each BH +
40 mm growable
suitable from SD 320 mm, each BH +
40 mm growable
optionally
optionally
with drum brakes, Commercially
available pneumatic tires in sizes 1
"(25.4mm), 1 3/8" (35mm) - sizes
355mm (20 "), 451mm (22"), 540mm,
(24 ") All puncture-proof tires in the
specified dimensions and 12"in size
ETRTO 47-203
diameter pipe
4° limited
height adjustment
+20/+40/+60 mm
height adjustment
+20/+40/+60 mm
height adjustment
+20/+40/+60 mm
height adjustment
+20/+40 mm
depending on camber and wheels
at BH 430 mm and 45° push handle
at BH 580 mm and 45° push handle
at 0° tilting and 0° back angle
depending on the size
inkl. seat shell
frame, seat plate, trum brake, hand-
rim, caster, leg support, push handle,
tilting-mechanism
