5 Technical specifications

5.1 Data and measurements

Model: Loop RS
SORG
German Aid Indix Nr.:
Type: 803
All measurements ± 5%
Indication
seat width (SW)
seat depth (SD)
back height (BH)
back angle
lower leg length
back angle with gas
pressure spring
leg support
tilting
ETRTO wheel size
ETRTO wheel size
ETRTO wheel size
handrim
camber
Seat height (SH)
with horizontal seat and
horizontal frame
wide wheelchair
absolutely
Wheelchair length ab-
solut
Wheelchair height ab-
solut
Height wheelchair fol-
ded back
incline
descent
stability
turning circle
load capacity (max.)/
weight testdummy
tare
heaviest weight
wheels
corrosion protection
length of use of the
wheelchair
life cycle of the wheelchair
Normative requirements
38 of 40
18.50.03.2001
Measurements
20-mm-steps 300 to 480 mm
20-mm-steps 300 to 480 mm
50-mm-steps 300 to 600 mm
80° to 120°
150 - 550 mm
90° to 117°
about 60 mm forward displaceable
from -3° to +34°
at 20" Ø 451 mm
at 22" Ø 489 mm
at 24" Ø 540 mm
Ø 19 mm
0° or 2°
rear wheel 410 mm
20"/22" 500 mm
caster 5"/5,5"
A-Rad 20"/22" 430 mm
Lenkrad 6"/7" 530 mm
A-Rad 24" 460 mm
Lenkrad 5"/6" 530 mm
A-Rad 24" 505 mm
Lenkrad 7" 550 mm
min. 520 mm
max. 810 mm
min. 790 mm at 20" , standard leg support
max. 1200 mm bei 24" rear wheel, seat depth 480 mm, detachable leg support
min. 830 mm
max 1430 mm
min. 550 mm
max. 620 mm
12% = 7°
12% = 7°
12% = 7°
ca. 1100 mm
120 kg
roadworthy 19,5 kg
at:
seat height
300 mm, rear
wheel 20",
caster 5" PU
rear wheel 1,2 - 2,2 kg
leg support from 2 kg
commercial pneumatic tires, sizes 1 ", 1 3/8" or puncture-proof tires (same dimensions), tire
inflation pressure usually 3-10 bar
material Stainless steel, aluminum
coating Powder coating, galvanizing
3 years at not excessive demand
5 years
The wheelchair meets the requirements of ISO 7176-8 and the requirements against
ignition.
Service Record Loop
Comment
+40 mm growable
± 20 mm (optional + 60 mm) growable
+50 mm growable
in raster
infinitely variable
infinitely variable
infinitely variable
444 mm Commercially available pneumatic tires
in the sizes 1 "(25.4mm), 1 3/8" (35mm)
481 mm - sizes 355 mm (20 "), 451 mm (22"), 540
mm, (24 ") All puncture-proof tires in
533 mm the mentioned dimensions.
diameter pipe
4° limited
height adjustment
+20/+40 mm
height adjustment
+20/+40 mm
height adjustment
+20/+40 mm
height adjustment
+20/+40 mm
depending on camber and kind of wheel
at BH 300 mm and
22" rear wheel
at BH 600 mm and 24" rear wheel
at 0 ° tilt and 0 ° tilt of the back angle
depending on the size of the wheelchair
inkl. seat shell
frame, seat plate, trum brake, handrim,
caster, leg support, push handle, tilting
mechanism
depending on the design and size
RS
