Removing the chassis management card from the EMX0 PCIe3
expansion drawer
To remove the chassis management card from the EMX0 PCIe3 expansion drawer, complete the steps in
this procedure.
Procedure
1. Ensure that you have the electrostatic discharge (ESD) wrist strap attached. If not, attach it now.
2. Ensure that the power supplies of the EMX0 PCIe3 expansion drawer are in standby. A power supply
is in standby when the input power LED (A) is on solid and the output power LED (B) is flashing.
See Figure 3.
Note: Fans continue to operate while the power supplies of the EMX0 PCIe3 expansion drawer are in
standby.
Figure 3. Power supply LEDs of an EMX0 PCIe3 expansion drawer
3. Disconnect the power cord from the power supply by pulling the power cord (A) out of the power
supply (C) in the direction shown in Figure 4 on page 4. Repeat this step for the remaining power
supply. Both power cords must be disconnected before you continue with the next step.
A
B
Chassis management card
3
