1. GENERAL INFORMATION

1.1. Introduction

The Local Area Network (LAN) option for the Genesys
user to remotely program, measure and check status of the power supply. It uses an
Ethernet connection like those used to connect computers to each other and to the Internet
A computer's web page browser may be used to operate the power supply through a built-
in web page server. For applications including factory and test automation, communication
may be done using several standard network protocols and instrument commands
Refer to the Genesys
safety requirements, specifications, connecting the power-in and out, operating the front
panel, using the serial (RS-232/485) programming and the analog (J1) programming
LAN Enable
Switch
8303460000 Rev A
TM
Technical Manual for information on installing the power supply,

Figure 1. Front Panel LAN Features

Link and Activity
LED
Green
LAN Status
RJ-45
LEDs
Ethernet

Figure 2. Rear Panel LAN Features

4
TM
series power supply allows the
Collision
LED
Green
Red
Green
Future
Connector
