CHAPTER 1: GENERAL INFORMATION

1.1

Introduction

The EtherCAT option for the
and check status of the power supply by EtherCAT (CANopen over EtherCAT) protocol implementation. Refer
to SAFETY & INSTALLATION manual (IA761-04-01_) for information on safety requirements,
specifications and installation. Refer to
supply operation.
RUN LED
1.2

Feature Summary

A. Communicate over EtherCAT network
CoE (CANopen over EtherCAT).
•
B. Full remote programming and monitoring functions
Uses EtherCAT (CANopen over EtherCAT) command language.
•
Compatible with EtherCAT test & measurement utilities.
•
C. Front Panel features
View MAC address.
•
EtherCAT (OPT) reset.
•
• Remote "Blink" identity function to locate the power supply in a rack.
D. Rear Panel features (2-Port EtherCAT)
Two Ethernet RJ-45 connectors (standard 8 pin jack).
•
• Allow connection of EtherCAT IN and OUT chain.
RUN, ERROR and two ports link/activity indicators.
•
power supply series allows the user to remotely program, measure
Link/Activity LED
(IN Port)
EtherCAT RJ45
IN Port
Figure 1–1: Rear Panel EtherCAT View
USER MANUAL (IA761-04-02_) for information on power
Link/Activity LED
(OUT Port)
EtherCAT RJ45
OUT Port
1
ERROR LED
