24.1.1 Emergency CH/GID Type

You can configure the type of CH/GID that operates in
Emergency Mode.
You can configure the Emergency Channel Type using
KPG-89D. The following Emergency CH/GID Types are
available.
Table 24-1 Emergency CH/GID Type Operation
Emergency
CH/GID Type
The transceiver transmits/receives
Selected using the Selected CH/GID when it
enters Emergency Mode.
The transceiver transmits/receives
using the Zone-CH/GID configured
Fixed
in Emergency Zone-CH/GID when it
enters Emergency Mode.
!
Configuration using KPG-89D
•
Configuring the Emergency CH/GID Type (Refer
to FPRG 6.14.1 Emergency CH/GID Type.)

24.1.2 Emergency Zone-CH/GID

This function allows you to configure the Emergency
Zone-CH/GID when "Fixed" is selected in Emergency CH/
GID Type.
The transceiver moves to the Emergency Zone-CH/GID
in the following way.
Table 24-2 Moving to Emergency Zone-CH/ GID
Model
•
•
TK-2180/ 3180
•
TK-7180/ 8180 •
Note: The transceiver does not decode the Stun Code and
Optional Signaling in Emergency Mode.
!
Configuration using KPG-89D
• Configuring the Emergency Zone-CH/GID (Refer
to FPRG 6.14.2 Emergency Zone-CH/GID.)
Version: 1.11
Operation
Operation
Press the PF Emergency key.
The switch that is connected to the
Man Down Switch Input port
becomes active.
Press the PF Emergency key.
Enable the Emergency port
assigned to AUX input port.

24.1.3 Emergency Cycle

This function allows you to configure the time for
switching between transmission and reception in
Emergency Mode.
You can configure the Emergency Cycle using KPG-89D.
The following Emergency Cycle operations are available.
Table 24-3 Emergency Cycle Operation
Emergency Cycle
1 - 200
Infinite
!
Configuration using KPG-89D
•
Configuring the Emergency Cycle (Refer to FPRG
6.14.3 Emergency Cycle.)

24.1.4 Locator Tone 1 Duration

The Locator Tone 1 Duration notifies a user that the
transceiver started the automatic transmission in
Emergency Mode.
The Tone sounds when the transceiver switches between
transmission and reception while it repeats the automatic
transmission and reception.
A user can easily recognize that the transceiver is about
to transmit the Emergency Call when the tone sounds.
You can also use the Tone to locate a user who is in an
emergency situation.
You can configure the Locator Tone 1 Duration using
KPG-89D.
!
Configuration using KPG-89D
•
Configuring the Locator Tone 1 Duration (Refer to
FPRG 6.14.4 Locator Tone 1 Duration.)

24.1.5 Transmit Duration

The transmission duration is the automatic transmission
time in Emergency Mode.
The transceiver performs automatic reception in
Emergency Mode after the Transmit Duration Time
expires.
You can configure the Transmit Duration using KPG-89D.
!
Configuration using KPG-89D
Function Reference
24 EMERGENCY MODE
Operation
The transceiver repeats "automatic
>
transmission start tone" "automatic
>
transmission" "automatic
>
transmission end tone" "automatic
reception" for configured times and
exits from Emergency Mode.
The transceiver keeps alternating
transmission and reception until the
PF Emergency key is pressed again
or the transceiver is turned OFF.
