Spectrum Controls InView Series User Manual page 88

4-24 Chapter 4: InView Protocol
Beg of
ADDR FUNC
Frame
: FF 01
NOTE
Beg of
ADDR FUNC
Frame
: FF 01
NOTE
Beg of
ADDR FUNC
Frame
: FF 01
NOTE
User's Manual 0300277-02 Rev. D
Transmission for Downloading Message 1 (Example 1)
H.O L.O
ADDR ADDR
00 64
See InView Display Communication Protocol Functions and Descriptions
on for further explanation of the InView sign protocol being used.
Response: NONE
300 ms pause
Download message file #002
Transmission is as follows:
Transmission for Downloading Message 2 (Example 1)
H.O L.O
ADDR ADDR
00 64
See InView Display Communication Protocol Functions and Descriptions
on for further explanation of the InView sign protocol being used.
Response: NONE
300 ms pause
Download message file #003
Transmission is as follows:
Transmission for Downloading Message 3 (Example 1)
H.O L.O
ADDR ADDR
00 64
See InView Display Communication Protocol Functions and Descriptions
on for further explanation of the InView sign protocol being used.
Response: NONE
DATA
^AZ00^BA2001^["b^I^^1^\1Priority
High^D
DATA
^AZ00^BA1002^["b^I^^1^\1Priority
Medium^D
DATA
^AZ00^BA0003^["b^I^^1^\1Priority
Low^D
Ready to
EOF rec.
response
CR LF
Ready
EOF to rec.
response
CR LF
Ready
EOF to rec.
response
CR LF
