1-2
AVERTISSEMENT
NOTE
Section 1.3
Change the
Serial Address
Section 1.4
Checkout Procedure
WARNING
AVERTISSEMENT
User's Manual 0300277-02 Rev. D
Chapter 1: Installing InView Message Display
Actions ou situations risquant de provoquer une explosion dans un
environnement dangereux et d'entraîner des blessures pouvant être
mortelles, des dégâts matériels ou des pertes financières.
Power wiring must be in accordance with Class I, Class II and Class III
Division 2 wiring methods (Articles 501-4(b), 502-4(b) and 503-3(b) of
the National Electrical Code, NFPA 70) and in accordance with the local
authority having jurisdiction.
A serial address for an InView sign is a number from 1 to 254 in hexadecimal (01
to FE). All signs leave the factory with a default address of 1 or 01.
This serial address is resident in the InView display and is used for RS-485
networking. If one of the factory network communications modules are used
(2706-Pxxx-SCx), this serial address is typically left at its factory default and the
network node or IP address is set in the factory network communication module.
After you install a sign according to the Electrical and Mounting Instructions,
make sure the sign is installed properly by applying power to it. The following
information should be displayed on the sign.
•
Firmware part number and version letter (xxxx).
•
Amount of RAM in the sign, (256 K).
•
Serial address of the sign (a number from 01 to FE or from 1 to 254).
Hazardous voltage.
Contact with high voltage may cause death or serious injury.
Always disconnect power to sign prior to servicing.
Tension dangereuse.
Tout contact avec une tension élevée peut entraîner la mort ou des
blessures graves.
Déconnectez toujours l'alimentation de l'afficheur avant toute
opération de maintenance.
