Spectrum Controls InView Series User Manual page 84

4-20 Chapter 4: InView Protocol
Beg of
ADDR
Frame
: FF
NOTE
Beg of
ADDR
Frame
: FF
NOTE
Beg of
ADDR FUNC
Frame
: FF 06
User's Manual 0300277-02 Rev. D
Transmission for Setting Date
H.O L.O
FUNC
ADDR ADDR
01 00
See InView Display Communication Protocol Functions and Descriptions
on for further explanation of the InView sign protocol being used.
Response: NONE
300 ms pause.
2. Set the day of the week.
The following transmission is used to remove the time that was just
loaded into the message queue.
Transmission is as follows:
Transmission for Setting Day of Week
H.O L.O
FUNC
ADDR ADDR
01 00
See InView Display Communication Protocol Functions and Descriptions
on for further explanation of the InView sign protocol being used.
Response: NONE
300 ms pause.
3. Clear the message queue.
The following transmission is used to remove the date and day of week that was
just loaded into the message queue.
Transmission is as follows:
Transmission for Clearing the Message Queue
H.O L.O
ADDR ADDR
00 65
Response: NONE.
Preview a Message
DATA
64 ^AZ00^BE;01040^D
DATA
64 ^AZ00^BE&5^D
DATA
FFFF
Ready to
EOF rec.
response
CR LF
Ready to
EOF rec.
response
CR LF
Ready to
LRC
EOF rec.
Error
response
98 CR LF
