Appendix A: Installing InView
Marquee 2706-P9xC2-SC
Message Displays
The information in the following section applies only to the C2 displays
and is identical to the information provided in the installation instruction
booklet, PN 0100267-01_A0(INSTALLATION_INSTRUCTIONS,2706-
P9xC2-SC) shipped with your display.
These instructions show you how to mount InView 2706-92C2-SC and 2706-
94C2-SC signs with NEMA Types 4, and 4X enclosures. These signs are
intended for indoor use.
•
Type 4 enclosures are intended to provide a degree of protection against
windblown dust and rain, splashing water, and hose-directed water.
•
Type 4X enclosures are intended to provide a degree of protection
against corrosion, windblown dust and rain, splashing water, and hose-
directed water.
Install the InView display conforming to all locally in effect, Electrical Safety
Requirements for Employee Workplaces. In addition to the NFPA general
guidelines, refer to the following:
•
Careful cable routing helps minimize electrical noise. Route incoming
power to the module by a separate path from the communication cables.
•
Wire used for installation must be rated higher than 75° C (167° F) or
15° C (59° F) above ambient temperature.
You can configure your InView Communications module or Messaging
software without having an InView display connected.
There are two InView C2 models, 2706-92C2-SC and 2706-94C2-SC. These
displays provide 10, user-selectable colors for fonts and bitmaps. The displays
provide a 1800 NITs brightness level. Power consumption is also much lower
than the previous models of P9 InView displays. The resolution is 6.25 mm
versus 7.5 mm. You may scroll images and characters from right-to-left, or left-
to-right, depending on the language. The displays comply with NEMA 4 and
IP66 housing standards.
If you use the equipment in a manner not specified by Spectrum Controls,
Inc. may impair the protection provided by the equipment.
User's Manual 0300277-02 Rev. D
