Parts List
Item Name
A
B
Appendix B: Installing InView Marquee 2706-P4xC2-SC Message Displays B-3
2706-P42C2-SC Rear View with Rear Access Panel Covers Removed
2706-P42C2-SC Bottom View
2706-P44C2-SC Top View
2706-P44C2-SC Rear View with Rear Access Panel Covers Removed
2706-P44C2-SC Bottom View
Ceiling Mount
Micro SD Card Access Panel
Description
Optional ceiling mount. Attach
provided hanging brackets
here.
Removal panel to access Micro
SD card.
User's Manual 0300277-02 Rev. D
