1-26
NOTE
NOTE
Pin
1
2
3
Pin
1
2
3
User's Manual 0300277-02 Rev. D
Chapter 1: Installing InView Message Display
To satisfy all agency requirements and ensure proper operation, power this
product using a 24 VDC, class 2 SELV power supply.
Use a small screwdriver to remove the terminal block's header to ease
product wiring.
Communication Connections for 2706-P22-SC Display
RJ12 Connections
Pin Name
+5 V
NC
TX
RS-485 Connections
Pin Name
E-GND
SHLD
COMM
Pin
Pin Name
4
5
6
Pin
Pin Name
4
5
6
RX
NC
GND
CH A
CH B
TERM
