1.9.2 DIP Switch Settings for 2706-P22-SC Display

The 2706-PCable1-SC is used for downloading messages only, and must be
removed after downloading is complete.
Disconnect power from the InView display before setting any switch.
WARNING
Switch settings are scanned only on power-up.
Coupez l'alimentation de l'afficheur InView avant de régler tout
WARNING
interrupteur. Les réglages des interrupteurs ne sont scrutés qu'à la mise
sous tension.
DIP Switch Settings
Pin Pin Name
1 1 (LSB)
2
3
4
3
Chapter 1: Installing InView Message Display
NC
TXD
RXD
NC
GND
2
4
8
16
Pin Pin Name
6
7
8
9
Pin Pin Name
6
7
8 128 (MSB)
9 Diagnostics
10 Not Used
