Spectrum Controls InView Series User Manual page 52

2-12 Chapter 2: InView System Connectivity
NOTE
User's Manual 0300277-02 Rev. C
Under the section with the Heading TCP/IP settings is the Configure
Communications button.
4. Click to access the Ethernet TCP/IP Communications window to set the
IP address.
5. In the IP Address field, specify the IP address.
6. If you are using the 2706-PENET1-SC, specify 3001 for the Port
address.
7. Enter the MAC Address of the module under the heading Assign IP
Address. The MAC Address is found on the module itself.
The 2706-P9x-SC display does not use MAC Address. IP Address
changes must be done serially.
8. Click the Setup button located in the section titled Assign IP Address
once the desired IP Address, Port, and MAC Address have been entered.
9. If the IP Address is already in use, an error message window appears.
