4-42 Chapter 4: InView Protocol
Display Position
Display
Position
Top Displays text on top line only.
Displays text on bottom line
Bottom
Middle
Fill

ASCII Characters

NOTE

Reference Material

User's Manual 0300277-02 Rev. D
Fill
Valid Modes used in P72 Series Displays
Description
only.
Not used.
Displays full screen of text.
You can enter extended ASCII characters directly within the text of a message.
Some of the characters may not show up depending on the fonts on your PC.
Please refer to the software help, 2706-PSW1-SC, for a complete listing of the
extended ASCII character set.
You must preview your message to view the extended characters when
using the InView Messaging Software.
For additional information refer to, Modicon Modbus Protocol Reference Guide,
PI-MBUS-300 Rev C.
P44 Series
Displays two lines of 7 pixel characters.
P74 Series
Comment 1
If the top line has only
one row of text, the
remaining bottom rows
are considered bottom.
If the bottom line only
has one row of text, the
remaining top rows are
considered top.
Not used.
Can be used to display
Fancy 16 Pixel or 16
Pixel characters.
Description
Comment 2
If the top line has
only two rows of
text. The remaining
bottom row is
considered bottom.
If the bottom line has
two rows of text, the
remaining top row is
considered top.
Not used.
