ITech IT6000C Series User Manual page 82

Load-Dump Load dump curve
Copyright © Itech Electronic Co., Ltd.
Select the voltage/duration
of 24V starting profile cor-
responding to Level 1.
1
Select the voltage/duration
of 24V starting profile cor-
responding to Level 2.
2
Select the voltage/duration
of 24V starting profile cor-
responding to Level 3.
3
Select centralized load dump
Test A
unsuppression
Select the 12V voltage
12V
system
Td
Un
Select the 24V voltage
24V
system
Td
Un
Test B Select centralized load dump
suppression
Select the 12V voltage
12V
system
Td
Un
Select the 24V voltage
24V
system
Td
Un
Us
Power Supply Function
Pulse width
Peak voltage
Pulse width
Peak voltage
Pulse width
Peak voltage
Pulse width
Peak voltage
Clamping voltage
71
