Recall the Vehicle Waveform
Select any of the above five kinds of vehicle waveforms, after completing the
waveform parameter setting (see the subsequent introduction for each parame-
ter), the system will automatically enter the waveform recalling mode and wait
for the triggering operation. At this time, the VFD screen is displayed as the
main interface of the system, and the corresponding waveform name is dis-
played in the lower right corner.
Run the Vehicle Waveform
After turning on [On/Off], the output of the vehicle waveform is triggered accord-
ing to the selected trigger method.
Stop the Vehicle Waveform Running
If you want to stop during the vehicle waveform output, you can do the following:
Press the composite keys [Shift]+[I-set] (Function) on the front panel to enter
the function menu.
At this point, the interface will prompt whether to stop the running of the Func-
tion (FUNCTION STOP?), you can press the Left/Right key to select Yes, then
the current running will be stopped, and the Function menu item will be dis-
played, you can re-enter the Function menu for editing; if No is selected, it
means that the current running will not be stopped, and the main interface of the
system is displayed.
4.6.3.1 Automotive Starting Waveform
The IT6000C series power supply has built-in 12V or 24V DIN40839 waveform.
This test verifies the behavior of a DUT during and after cranking. This wave-
form can reproduce the voltage curve for automotive power network confirms to
DIN40839 standard, thus facilitating quick call by customers.
SAEJ1113-11
LV124
The trigger method of the vehicle waveform is consistent with the trigger
method of the List function, that is, the List trigger source is also effective for
the vehicle waveform.
Copyright © Itech Electronic Co., Ltd.
Power Supply Function
SAEJ1113-11 Waveform protocol
LV124 Waveform protocol
