Select Curve file
You can select the Curve file saved in the instrument to be in the Open state for
later running.
1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-
2. Use knob or Up/Down key to select 4. SAS: Off and press [Enter].
3. Press the Left/Right key to select Static and press [Enter].
4. Press the Left/Right key to select Curve and press [Enter].
5. Press the Left/Right key to select Open and press [Enter].
6. Set the name of the Curve file to be recalled (i.e. the file name set in Edit)
Run the Static PV Curve
•
•
Run Vmax Static
ter the function menu.
and press [Enter].
At this point, the system returns to the main interface of the SAS function,
and the currently selected Curve file is to be run. The interface is displayed
as follows:
FUNCTION SAS
Run Vmax Static
Curve
1. Refer to Select Curve file
2. Set the Vmax and Filter as the actual test needs.
3. Press the Left/Right key on the SAS main interface to select Run and
press [Enter].
At this point, the instrument enters the SAS mode, and the VFD screen is
displayed as the main interface of the system, waiting to trigger the Curve
file to run.
4. Turn on the [On/Off].
5. Based on the selected trigger method, perform the trigger operation.
The trigger method of the SAS function is consistent with the trigger
method of the List function, that is, the List trigger source is also effec-
tive for the SAS function.
User-defined
Copyright © Itech Electronic Co., Ltd.
Table Filter
Table Filter
to select the Curve file to be run.
