2.5.2.1 Using Web Server
The instrument has a built-in Web server for monitoring and controlling the in-
strument via a Web browser in PC. To use the Web server, connect the instru-
ment and PC over LAN interface and enter the instrument's IP address into the
address bar at the top of your PC's Web browser, you can access the front pan-
el control functions including the LAN configuration parameters.
•
•
The opened page is displayed as follows:
You can select different pages by clicking the buttons shown in the navigation
bar on the left side of the window. The detailed descriptions are as follows.
•
•
If you want to remotely control the instrument using the built-in web server, you
must enable the web service. See
The format of the address entered in the address bar of the browser is http://
192.168.0.100. The specific IP address is subject to the actual instrument
settings.
The homepage of different models are different. The actual shown page shall
be subject to the connected instrument.
Home:Web home interface, displays the model and appearance of the
instrument;
Information: Displays the serial number of the instrument and more system
information as well as LAN configuration parameters;
Copyright © Itech Electronic Co., Ltd.
Inspection and Installation
2.5.2 LAN Interface
for details.
31
