This instrument supports battery discharge test in constant current and con-
stant power modes. If the user wants to discharge in constant current mode,
enter the Config menu, select the CC priority, set Vl to 0, set Vh to the rated
voltage value of the instrument, set P- to the rated power value of the instru-
ment, and then set the Battery menu according to the test requirements. If
the user wants to discharge in constant power mode, set P- to the specified
value, and set Discharge V and Discharge I to the rated voltage and current
value of the instrument.
1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-
ter the function menu.
2. Use knob or Up/Down key to select 2.BATTERY: Off and press [Enter].
The interface is displayed as follows:
FUNCTION BATTERY
Run Edit
3. Press the Left/Right key to select Edit and press [Enter].
4. Press the Left/Right key to select Charge or Discharge and press [Enter].
5. Set the charging voltage (Charge V) or discharging voltage (Discharge V),
charging current (Charge I) or discharging current (Discharge I) and the
other parameters, and then press [Enter] to confirm.
After the parameter setting is completed, the interface returns to the Battery
function main interface and displays as follows:
FUNCTION BATTERY
Run Edit
6. Press the Left/Right key to select Run and press [Enter].
The instrument will enter the battery test mode and wait for the battery test
to be triggered.
7. Turn on the [On/Off].
This product supports Sense anti-reverse function. If you reverse the
Sense cables, the VFD will display a negative voltage value, and you can-
not turn on the output at this time. It can only be turned on after the cables
are properly connected.
8. Based on the selected trigger method, perform the trigger operation.
