Protection Delay
You can specify an OCP/OVP/OPP/UCP/UVP delay to prevent momentary out-
put settings and status changes from tripping the protection. In most cases
these momentary conditions would not be considered an protection fault, and
having an OCP/OVP/OPP/UCP/UVP condition disable the output when they oc-
cur would be a nuisance. Specifying an protection delay (Delay) can ignore
these momentary changes during the specified delay period. Once the delay
time has expired and the protection limit condition persists, the output will shut
down.
Protection Prompt
When the instrument enters the protection state, the buzzer sounds (if Beep
menu item is set as default state On), the VFD status indicators Prot and Off
are lit, and [On/Off] is turned off.
When protection is generated, the VFD screen displays the following
information:
•
•
Clear the Protection
After the instrument triggers protection and generates a protection message,
you need to troubleshoot the possible cause. When the protection is resolved,
Although [On/Off] is turned off, there may be dangerous voltage at
the output electrodes. Do not touch the wiring cable or the electrode
terminals.
The first row shows the meter voltage and the meter current value.
The second row shows specific protection information, such as OVP.
Copyright © Itech Electronic Co., Ltd.
Power Supply Function
condition should not be
considered as an
undervoltage fault and
there is no need to trig-
ger protection.
Level UVP limit
Protection delay time,
Delay
see Protection Delay.
