Pins Description
It can output a voltage of 0 to 10V to monitor the output current
from negative full scale to positive full scale.
7 Reference voltage (10V) test terminal. The accuracy is 0.03%.
You can use a multimeter to measure this pin. When the output
voltage of the pin is in the range of 10±0.03%*10, it indicates that
the accessory is functioning normally. Otherwise, the function is
abnormal and cannot be used.
8 Terminals for external analog function. .
9
10
