two pins of the CAN interface, you also need to connect a ground pin, which is
pin 8 of the digital I/O interface.
Definition of CAN Pins
The definition of CAN pins are as follows.
Pins
H
L
GND
CAN Configuration
The user needs to configure the CAN interface parameters in the system menu
before using the remote control. The CAN interface parameters are as follows.
Name
Baud rate
Instrument
Address
Prescaler
BS1
BS2
The operation steps are as follows.
1. Press the composite keys [Shift]+[P-set] (System) on the front panel to en-
2. Rotate the knob or press the Up/Down key to select I/O and press [Enter].
Be sure to connect the GND terminal correctly. Using the CAN com-
munication interface when the GND terminal is not connected may re-
sult in unstable communication or damage to the CAN interface.
Description
Select the baud rate from the following options: 20k/40k/
50k/80k/100k/125k/150k/200k/250k/400k/500k/1000k
Range: 1 – 65535
Not settable. Change with Baud rate setting
Not settable. Change with Baud rate setting
Not settable. Change with Baud rate setting
ter the system menu.
Copyright © Itech Electronic Co., Ltd.
Description
CAN_H
CAN_L
Pin 8 (GND) of the digital I/O interface.
