Introduction

Connect Tech's Elroy Carrier for
TX2i or TX1 Solution to the market. Designed to match the NVIDIA® Jetson™ TX2, TX2i or TX1 module form
factor, the Elroy's design includes Dual MIPI CSI-2 Video Inputs, Mini-PCIe/mSATA expansion, Gigabit Ethernet,
HDMI Video, USB 3.0 and 2.0, and two Serial Ports for RS-232/485.
All of this is designed for use in a small form factor rugged environment. With locking pin-header connectors,
solder in standoffs, and industrial temperature range components, the Elroy is going places.

Product Features and Specifications

Feature
Module Compatibility
PCB Size / Overall Size
Display
Ethernet
USB
SATA
Audio
Serial
Mini-PCIe/mSATA
SD Card
Video Input
Misc.
Power Requirements
Operating Temperature
Weight
Accessories
Warranty and Support
Document: CTIM-00465
Revision: 0.16
NVIDIA® Jetson™ TX2/TX2i/TX1
Elroy Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
NVIDIA® Jetson™ TX2, TX2i or TX1
87mm x 50mm (3.425" x 1.968")
3D STEP Model: download here
1x HDMI
1x Gigabit Ethernet (10/100/1000)
1x USB 3.0 (Integrated USB 2.0)
1x USB 2.0
1x mSATA Half or Full Size
(Use of Full Size Removes Secondary Mini-PCIe Slot)
HDMI Integrated
2x RS-232/RS-485
1x Mini-PCIe/mSATA Half or Full Size
(Use of Full Size Removes Secondary Mini-PCIe Slot)
1x Mini-PCIe Half Size
1x microSD Card Slot
2x 2-Lane MIPI CSI 2.0
1x I2C Link
1x SPI Link
1x System Control
4x GPIO
+9V to +14V DC Input Range
o o
-40 C to +85 C
35g
Cable Kit
1 Year Warranty and Free Support
Page 7 of 30
Connect Tech Inc. 800-426-8979 | 519-836-1291
®
Elroy Carrier for NVIDIA
brings a low cost deployable Jetson™ TX2,
Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Date: 2019-02-20
