ESD Warning

Revision History

Revision
0.00 2016/04/28
0.01 2016/06/13
0.02 2016/07/07
0.03 2016/10/06
0.04 2016/10/14
0.05 2016/11/16
0.06 2016/11/24
0.07 2017/04/18
0.08 2017/04/24
0.09 2017/05/26
0.10 2017/08/04
0.11 2017/11/08
0.12 2017/12/06
0.13 2018/01/05
0.14 2018/03/08
0.15 2018/07/30
0.16 2019/02/20
Document: CTIM-00465
Revision: 0.16
Date
Initial Release
Added more technical information throughout the document
Fixed formatting on thermal section
Added information on USB Recovery Mode & fixed minipcie pinout
Revised information on USB recovery & added note on video input
Updated assembly drawings
Added note on power supply, MSG063
Updated MSG063 Cable Drawing
Added Note on P8, Added tags on mPCIe Pinout table
Updated power supplies; added TX2 specs
Added cable drawing links, removed drawings from doc
Added TX1/TX2 Compatibility information, updated block diagram,
updated SW section
Updated power specifications
Revised cable information
Added GPIO KDB link
Added TX2i compatibility
Added TX2i power circuitry note, pinouts to all photos, P4B to Video
Input, notes on CSI connection and SPI lanes
Page 6 of 30
Connect Tech Inc. 800-426-8979 | 519-836-1291
Elroy Carrier for NVIDIA
Electronic components and circuits are sensitive to
ElectroStatic Discharge (ESD). When handling any circuit
board assemblies including Connect Tech carrier
assemblies, it is recommended that ESD safety
precautions be observed. ESD safe best practices include,
but are not limited to:
•
Leaving circuit boards in their antistatic packaging
until they are ready to be installed.
•
Using a grounded wrist strap when handling circuit
boards, at a minimum you should touch a grounded
metal object to dissipate any static charge that may be
present on you.
•
Only handling circuit boards in ESD safe areas, which
may include ESD floor and table mats, wrist strap
stations and ESD safe lab coats.
•
Avoiding handling circuit boards in carpeted areas.
•
Try to handle the board by the edges, avoiding contact
with components.
Changes
Jetson™ TX2/TX2i/TX1
®
Users Guide
www.connecttech.com
Date: 2019-02-20
