Thermal Details

The Elroy Carrier Board has an Operating Temperature Range of -40°C to +85°C.
However, it is important to note that the NVIDIA Jetson TX2 and TX1 Modules have its own properties
separate to that of the Elroy Carrier Board. The NVIDIA Jetson TX2i matches the Elroy Operating
Temperature Range of -40°C to +85°C.
Customer responsibility requires proper implementation of a thermal solution that maintains the
TX2/TX2i/TX1 SoC and Thermal Transfer Plate (TTP) temperatures below the specified temperatures (shown
in the tables below) under the maximum thermal load and system conditions for their use case.
Jetson TX2i Thermal Specifications
Parameter
Maximum TTP operating temperature
Recommended Tegra X2 operating temperature limit
Tegra X2 maximum operating temperature limit
Jetson TX2/TX1 Thermal Specifications
Parameter
Maximum TTP operating temperature
Recommended Tegra X2 operating temperature limit
Tegra X2 maximum operating temperature limit
NVIDIA provides complete Thermal Design Guides, which include all of the information required to
implement a complete thermal solution for the Jetson TX2, TX2i or TX1 Module. The Thermal Design Guides
can be downloaded here:
Jetson TX2i:
http://developer.nvidia.com/embedded/dlc/jetson-tx2i-thermal-design-guide
Jetson TX2/TX1:
http://developer.nvidia.com/embedded/dlc/jetson-tx2-thermal-design-guide
Document: CTIM-00465
Revision: 0.16
Page 28 of 30
Connect Tech Inc. 800-426-8979 | 519-836-1291
®
Elroy Carrier for NVIDIA
Value
85
T.cpu = 95.5
T.gpu = 95.5
T.cpu = 101
T.gpu = 101
T.diode = 110
Value
80
T.cpu = 95.5
T.gpu = 93.5
T.cpu = 101
T.gpu = 101
Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Units
°C
°C
°C
°C
°C
°C
Units
°C
°C
°C
°C
°C
Date: 2019-02-20
